WH015
Weirdpower
| Bluetooth chip | Bluetrum AB5335B | ||||
| Bluetooth protocol | HSP V1.2, A2DP V1.2, AVRCP V1.4, HFP V1.6, DI V1.3; | ||||
| Bluetooth effective distance | 10 meters | ||||
| battery: | Pure battery 3.7V 200mA with protection PCBA | ||||
| Headphone Driver | 32Ω * 5mW; | ||||
| Working current: | about12mA | ||||
| Charging current: | about 70ma | ||||
| frequency: | 100Hz-10KHz; | ||||
| charging time | 2H | ||||
| Music playtime: | 17 hours, 24hours of talk time (70% sound volume) | ||||
| Charging Connector | Micro USB | ||||
| Operation Way | Button | ||||
| Material: | silicone | ||||
| Language | English power button： 1. Press and hold for 2 seconds to turn on and off 2. press pause/play/pick up and hang up the phone, and press reject the call for a long time 3. Double-click Call back | ||||
| “+” Button | Single press volume plus, Long press next song | ||||
| “-“ Button | Single press volume reduction, Long press upper song | ||||
| power button | 1. Press and hold for 2 seconds to turn on and off 2. Single press to pause / play / answer the call, and long press to reject the incoming call 3. Double-click Call back | ||||
| Light | 1. Red light when charging. When full will turn to blue light 2. The blue light flashes three times after turn on, 3. The red light flashes three times when turn off, 4. After pairing, the blue light flashes for 5 seconds， 5. When the red light flashing means the battery is Low power | ||||
| Bluetooth chip | Bluetrum AB5335B | ||||
| Bluetooth protocol | HSP V1.2, A2DP V1.2, AVRCP V1.4, HFP V1.6, DI V1.3; | ||||
| Bluetooth effective distance | 10 meters | ||||
| battery: | Pure battery 3.7V 200mA with protection PCBA | ||||
| Headphone Driver | 32Ω * 5mW; | ||||
| Working current: | about12mA | ||||
| Charging current: | about 70ma | ||||
| frequency: | 100Hz-10KHz; | ||||
| charging time | 2H | ||||
| Music playtime: | 17 hours, 24hours of talk time (70% sound volume) | ||||
| Charging Connector | Micro USB | ||||
| Operation Way | Button | ||||
| Material: | silicone | ||||
| Language | English power button： 1. Press and hold for 2 seconds to turn on and off 2. press pause/play/pick up and hang up the phone, and press reject the call for a long time 3. Double-click Call back | ||||
| “+” Button | Single press volume plus, Long press next song | ||||
| “-“ Button | Single press volume reduction, Long press upper song | ||||
| power button | 1. Press and hold for 2 seconds to turn on and off 2. Single press to pause / play / answer the call, and long press to reject the incoming call 3. Double-click Call back | ||||
| Light | 1. Red light when charging. When full will turn to blue light 2. The blue light flashes three times after turn on, 3. The red light flashes three times when turn off, 4. After pairing, the blue light flashes for 5 seconds， 5. When the red light flashing means the battery is Low power | ||||
